Exterior renovationsHow to paint a wooden deck: step-by-step instructions
If you’re one of the lucky ones, your home may have a beautiful outdoor space or backyard. A popular fixture in many yards is the patio. Also known as a deck, whether large or small, wood is commonly used as a material to construct these beautiful features.
As you may know, your wood will need to be treated in order to be safe for outdoor use while also maintaining its longevity.
In most cases, this will involve staining, priming and painting. Painting may obscure the surface of the wood, but is an excellent option to breathe new life into an older surface or give a unique touch to a new one.
For a step-by-step guide, we met with one of the contractors in our network, Felix Deblois-Beaucage, as he and his team were working on a wooden deck renovation project. Here, we’ll go over the five main steps of this process.
Before you begin painting, you’ll need to be sure that you're working on a clean surface. Be sure to fix any popped nails or screw heads that may have come loose. Also, if you find large cracks throughout the surface of the wood, these will need to be filled in before painting.
This can be completed with epoxy putty and then stained to match the surrounding deck boards. This step is especially important when working on a deck you plan to use for a number of years.
If your deck has several years of dirt, grime, and dust build-up, a deep cleaning process with a specific wood-safe cleaner is necessary. If the cleaning process has dampened the wood, let it dry before the next step.
Sometimes the drying process can take up to 48 hours and painting any earlier than this can compromise the wood. Otherwise, removing dust with a dry cloth should be a good enough treatment to the surface.
Once the surface of the wood has been treated for holes while also being clean and dry, you'll need to sand it with 50-grit sandpaper. This is an important step because any trace of old paint, primer, or stain should be removed from the surface of the wood before you go forward with adding another paint or primer.
Not to mention that sanding the surface works to open up the pores in the wood, which will improve the new paint or stain adhesion. If there's no paint, varnish, or stain on the wood, we recommend using 100 or 120 grit sandpaper. An electric sander is another tool that will make this step easier and speed up the process.
For our specific project, the contractor needed to sand twice to remove the old stain. In some cases, including when working on very old surfaces, you may have to use a chemical stain and sealer remover or a thermal removing technique. If the product you want to apply is sheer, this sanding step is paramount, as wood will show through the finish.
Looking for contractors to paint a wooden deck or structure?
Fill out the form so that we can put you in contact with certified contractors from our network!
Since the surface we’re working with is wood, it's advised to use a primer. Although some paints now come with a primer mixed in, we’d suggest that you opt for a separate primer. A separate primer will help to seal the wood and greatly improve the adhesion level of the finished paint. Therefore, the final result will be more durable.
This type of primer or sealer can easily be found in any local hardware or specialized paint store. Make sure to protect the surrounding surfaces with painter's tape or a plastic sheet, and this includes any vinyl cladding or deck accessories.
For elements not on the surface level of the deck, such as rails, handrails or caps, use a brush to stain these surfaces. When it comes to the rest of the deck’s surface, we’d recommend using a roller, as it will be able to cover more of an area in less time. Then, simply follow the manufacturer's recommendations for application methods as well as drying time.
Only when the primer is completely dry should you begin the painting process. For this specific project, two coats of opaque 100% acrylic paint were used. As we mentioned above, use a roller to apply the paint. The workers in this project used one for large areas and a paintbrush for corners and edges. Once the entire surface was covered, they let it dry according to the paint manufacturer's instructions.
When it comes to the painting of your deck, you could also cover the wood using a sealant or a stain. Do bear in mind that when working with a stain, anywhere between one and three coats may be necessary. However, this will be dependant on the type of stain you apply.
Use your personal judgment when it comes to deciding on the number of coats. Remember that paints and stains may dry differently than they appear going on.
After you’ve applied the right amount of paint coats to your deck's wood surface, you’ll then need to let it dry for at least 24 hours. Drying time may be dependant on the weather and this is an extremely important factor to consider. Before you start this project, we’d recommend checking out your local weather forecast to reveal the 24-48 hours during which you plan on undertaking this project. This is to make sure it’s clean, dry and not too humid. Unfortunately, if it happens to start raining before the paint dries, you may have to paint all over again.
Also, avoid painting on significantly hot days as high temperatures decrease paint adhesion. For optimal results, take the time to complete each step properly and respect weather conditions.
For our contractor, this project lasted three days. For you, it’s possible that it could take more or less time. If you're looking for a professional and refined result, we’d suggest hiring experienced contractors to carry out the job.
Lastly, we'd like to mention that if you're working with a stain, it's recommended to re-stain your deck every 1-3 years. This will continue to protect the surface and help the structure to last longer. If you use paint instead, it is advisable to repaint every 2 or 3 years.
If you do not have a patio and want to build one, read our article Deck Building Materials and Construction.
Would you like to have an estimation of the cost of your new deck? Try our cost calculator!
Renoquotes.com can help you get quotes to paint or stain a wooden deck. If you submit your project to us, we’ll put you in contact with the most suitable contractors for you. Fill in the form on our homepage (only a few minutes), and you will receive quotes from companies that are specialized in exterior painting.
