Exterior renovationsRenovation tipsHow to Maintain a Septic System
Do you live in a rural area or have a summer house with a wastewater disposal system that isn't connected to your local water systems? If so, you probably have a functioning septic system in place.
And since you want to adhere to the best practices to prolong the lifespan of your fixtures, and avoid equipment failure, you might need a few tips down the line.
Your on-site sewage disposal is made with PVC pipes that carry waste from your home to a tank buried on your property (your septic tank), which is connected to a disposal field. The disposal field system filters out pollutants, allows gases to safely evaporate through vents, and returns treated water to the ground.
Whether you have a conventional on-site disposal system or an advanced one, sooner or later, you'll need to grasp the basics of unclogging a pipe, pumping out sludge, cleaning a pre-filter, replacing a vent, and so on. Your safety and the longevity of your septic tank will depend on it. In a nutshell, it's your responsibility as a homeowner, such as stated in Quebec’s regulation on the disposal and treatment of wastewater from isolated dwellings.
For a properly functioning septic tank to last as expected (15 to 25 years), you need to keep it in good working condition. A poorly maintained septic tank can clog, collapse, cause diseases (to humans, wildlife, or plantlife), contaminate soils, or cause other serious problems.
To prevent these problems from occurring, drain your tank and have the entire system inspected every 2 years (if used on a regular basis). If your tank is located at your chalet, for example, where the influx of wastewater is minimal, plan to have it serviced every 4 years.
Source: Flickr
Having a septic tank requires one to be a little more diligent about water use and waste disposal. Septic systems are more prone to damage than city sewer systems. Many substances can't be broken down by the enzymes and bacteria in your tank; these substances can eliminate the bacteria needed to treat the wastewater and even clog your system. So, here are some tips to follow:
Source: Depositphotos
Are you looking for general contractors for your renovation project?
Fill out our form to receive quotes from certified contractors!
Biological additives (bacteria and enzymes) are marketed to improve septic tank and disposal field conditions, or to treat sludge and biomass build-up problems.
Several studies conducted between 2005 and 2020 have shown that additional bacteria or enzymes don’t actually have any measurable beneficial effects on the overall performance of a well-maintained septic system. If anything, adding extra microorganisms could potentially clash with the naturally occurring bacteria, competing for organic matter and oxygen to maintain the bacteria. Ultimately, the use of these additives will actually reduce the efficiency of the system. Generally speaking, it's enough to follow the above-mentioned tips to keep your system performing at optimum levels.
On the other hand, these sorts of products could be beneficial in the event that plant life in your tank has somehow been destabilized due to unwanted materials such as antibacterial soaps, pesticides, pharmaceuticals, and so on. So, it might be worth giving nature a helping hand.
In an interview with Grey Scarrot, an expert with Bio-Sol, several things were confirmed:
Source: Flickr
The cost of maintaining a septic system depends on a number of factors, including the type and age of the system, your area, land accessibility, and the company you hire.
RenoQuotes.com can help you get quotes for a septic system installation. By submitting your project, we’ll put you in contact with top-rated contractors. Fill in the form on the homepage (it only takes a few minutes), and you will get estimates from trusted professionals.
Last modified 2023-02-14
